101-00212 PRESSURE TESTER

OVERVIEW

The 2311FA Pressure Tester field tests aircraft pressure systems for both reciprocating and turbine engine pressure systems, it provides pressure for testing pressure transmitters, warning switches pressure-type torque indicators and system leak testing in the range of 0-600 psi, the unit consists of a cylinder equipped with a manually operated screw piston for developing pressure, a fluid reservoir is connected through a control valve to the pressure cylinder, The tester is portable and rugged, with a wide range capability, it is simple-to operate, self-contained and both line and shop proven.

FEATURES
• Manufactured with light-weight aluminum-alloy
• Field tests aircraft fluid pressure systems
• Provides for both leak and calibration tests
• Pressure source for pressure transducers warning switches and direct reading pressure gauges
• No electric or pneumatic source needed
• The use of VITON (Fluro-carbon) seals on the piston permits the use of any fuel, lubricating or hydraulic fluid
• Analog and digital gauges available
• The principal non compatible fluids not to be used with Viton seals are alcohols, aldehydes, amines, alkyl phosphate esters, ethers and ketones
