BACB30LM4-11 Wesco Machine Bolt, 1/4 in, UNJF, 0.42 to 0.43 in L Thread, 1/4 in Dia, 1-17/64 in L

Technical information

• FAA-NR Approved

Specifications

• Diameter: 1/4 in
• Dash Number: 11
• Thread Length: 0.42 to 0.43 in
• Thread Type: UNJF
• Head Diameter: 0.43 to 0.439 in
• Head Height: 0.125 to 0.14 in
• Head Type: Hexagonal
• Thread Size: 1/4 in
• Thread Per Inch: 28
• Grip Size: 0.677 to 0.697 in
• Thread Class: 3A
• Thread Direction: Right Hand
• Tensile Strength: 160000 psi
• Length: 1-17/64 in
• Material: Stainless Steel
• Finish: Cadmium-Plated
• Domestic/Import: Domestic
