Antennas, Avionics, Avionics & Instruments, Comant
CI-119 Comant VHF Comm Blade 4 Internal Hole Mount Offset
Part #: CI-119
CI119
R$7,054.05
CompararOverview
Comant’s four internal hole mount blade style VHF communication antenna with offset BNC port. Equivalent to the CI 138, CI 139 and CI 196 expect for variations to BNC location and hold pattern. Suitable for either top or bottom mounting with both light and heavy fixed wing single / multiengine and helicopter aircraft.
| Peso | 0.57 lbs |
|---|---|
| Brands |
Specifications
- Electrical
- Frequency: 118-137
- VSWR: 2.9:1 Max
- Polarization: Vertical
- Radiation Pattern: Omnidirectional
- Impedance RF: 50 Ohms
- Power RF: 25 Watts
- Mechanical
- Weight: 1.25 lb
- Height: 13 in
- Material Valox: 420
- Finish: Glossy White
- Connector: Offset BNC (female)
- Environmental
- Temperature: -55 to +85 Celsius
- Altitude: 35,000 ft.
- Federal Specifications
- FAA TSO: C37d, C38d
- RTCA Environmental: DO-160D
- Gasket: C12704 Cork Neoprene
