CI-2680-216 Comant Comdat VHF COMM/ XM Blade
Part #: CI-2680-216
CI2680216
R$13,704.33
CompararOverview
Comant’s ComDat® four through hole blade style mount VHF / XM Weather & Radio antenna with BNC / TNC ports. This antenna covers both VHF communication and XM frequencies. Designed to be used with Garmin XM panel mount systems. Suitable for top mounting with for both light and heavy fixed wing single engine / multi-engine and business jet aircraft
| Peso | 0.57 lbs |
|---|---|
| Brands |
Specifications
- VHF Characteristics
- Frequency: 118-137 MHz
- VSWR: 2.9:1 Max
- Polarization: Vertical
- Radiation Pattern: Omnidirectional
- Impedance: 50 Ohms
- Power Rating: 50 Ohms
- XM Weather Data Specification
- Frequency: 2332.5-2345.0 MHz
- VSWR: 2.0:1 Max
- Polarization: LHCP
- Radiation Pattern: Hemispherical
- Impedance: 50 Ohms
- Gain: 25 +/- 2 dB
- DC Voltage: 3.6 – 24 Volts
- DC Current Min/Max: 45mA Typical / 55 mA Max
- Mechanical / Environmental
- Weight: 1.25 lb
- RTCA Env. / TSO: DO-160D, TSO C169
- Connector: VHF – BNC / XM – TNC
