CI-401-460 Comant Comdat GPS Non-Waas / XM Rectangle
Part #: CI-401-460
CI401460
R$8,708.70
CompararOverview
Comant’s ComDat® four through hole rectangle style mount (ARINC 743A Footprint) GPS non-WAAS / XM Weather & Radio antenna with dual TNC ports. This antenna covers both GPS / XM frequencies. GPS C144 certified for class 1 LNAV approaches (lateral navigation only). Designed to be used with 27 dB gain GPS panel mount systems. Suitable for top mounting with both light and heavy fixed wing single engine / multi-engine and business jet aircraft.
| Peso | 0.18 lbs |
|---|---|
| Brands |
Specifications
- Specifications
- Comant: CI 401-460
- ComDat® GPS Non-WAAS Navigation / XM Weather & Radio
- GPS Preamplifier Characteristics
- Frequency: 1575.42 MHz
- VSWR: 1.5:1 Max
- Polarization: RHCP
- Radiation Pattern: Hemispherical
- Impedance: 50 Ohms
- Gain @ 1575.42 MHz: 27.0-30.5 dB
- DC Voltage: 4-24 Volts
- DC Current Min/Max: 25mA Min / 40mA Max
- Noise Figure: 3.8 dB
- Selectivity: -35 dB Min @ Satcom
- Frequency
- XM Weather Data Specification
- Frequency: 2332.5-2345.0 MHz
- VSWR: 1.5:1 Max
- Polarization: LHCP
- Radiation Pattern: Hemispherical
- Impedance: 50 Ohms
- Gain: 26-30 dB
- DC Voltage: 4 V Min / 4.7 Typical / 5.5 V Max
- DC Current Min/Max: 25mA Min / 45 mA Typ / 55 mA Max
- Noise Figure: 2.7 dB Max
- Mechanical
- Weight: 6.5 oz
- Finish: Glossy White
- Connector: GPS – TNC / XM – TNC
- Environmental
- RTCA: Env. DO-160D
- Federal Specifications
- TSO C144
