DMN4-4 Antenna, BNC Female Connector, 8-1/2 in H, 108 to 122 MHz, 50 Ohm, Horizontal
Part #:
DMN44
Comparar
Overview
The N4-4 is an airborne, true center-fed loop, navigation antenna. The N4-4 antenna system has been designed to minimize bearing errors in the reception of VOR and ILS signals. It provides considerably more gain at the horizon (particularly during banks) than do fuselage mounted deerhorn or vee antennas.
| Peso | 2.5 lbs |
|---|---|
| Dimensões | 21.25 × 14.38 × 5.25 in |
| Brands |
SPECIFICATIONS
• Series: N4
• Frequency Rating: 108 to 122 MHz
• Dimensions: 8-1/2 in H
• VSWR: <5:1
• Polarization: Horizontal
• Impedance: 50 Ohm
• Pattern: Omni-Directional/Cos q
• Connector Type: BNC Female
FEATURES
• Very high frequency omni-directional radio range localizer antenna designed for high performance aircraft
• Rugged design to ensure reliability in severe environments
• Variants can be utilized for new aircraft install or retrofit applications
TECHNICAL INFORMATION
• FAA TSO-C40A Compliant
• MIL-E-5400, MIL-T-5422 Qualified
