MS21060L06 Self-Locking Double Lug Floating Nut Plate, #6, 32 TPI, Stainless Steel, Passivated

TECHNICAL INFORMATION

• FAA-STD Approved
• AMS 2410 Specified

SPECIFICATIONS

• Dash Number: L06
• Width: 0.29 to 0.416 in
• Finish: Passivated
• Material: Stainless Steel
• Lubrication: Dry Film
• Mounting Hole Center-to-Center: 0.686 to 0.69 in
• Mounting Hole Diameter: 0.098 to 0.103 in
• Mounting Type: Straight Hole
• Number of Holes: 2
• Nut Dimensions: 0.948 in L x 0.203 in H
• Temperature Rating: 450 deg F
• Thickness: 0.032 in
• Thread Class: 3B
• Thread Direction: Right Hand
• Thread Per Inch: 32
• Thread Size: #6
• Thread Type: UNJC
• Domestic/Import: Import
