NAS623-2-2 Short Threaded Machine Screw, #8-32, UNC, 0.189 to 0.301 in L Thread

TECHNICAL INFORMATION

• National Aerospace Standard
• AMS-QQ-P-416 Type II Class 2
• MIL-S-5626/MIL-S-5000/MIL-S-6049 Qualified
• FAA-STD Approved

SPECIFICATIONS

• Diameter: #8
• Length: 0.401 in
• Thread Size: #8-32
• Thread Type: UNC
• Head Type: Pan
• Thread Direction: Right Hand
• Material: Alloy Steel
• Drive Type: Phillips
• Finish: Cadmium
• Thread Length: 0.189 to 0.301 in
• Thread Class: 3A
• Head Diameter: 0.306 to 0.322 in
• Head Height: 0.105 to 0.115 in
• Grip Size: 1/8 in
• Grade: 4140/E4340/8740
• Tensile Strength: 160000 psi
• Domestic/Import: Domestic
