Aircraft Parts, Engine Parts, Magnetos & Parts, Slick 6300 Parts
SLICK OIL SEAL M3331
Part #: M3331
R$259.03
Comparar| Peso | 0.01 lbs |
|---|---|
| Dimensões | 1.19 × 1.19 × .32 in |
| Brands |
Reference Chart
| Description | 6310 | 6314 | 6320 | 6324 | 6331 | 6340 | 6350 | 6351 | 6355 | 6360 |
| Cotter pin | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 |
| Nut, Impulse Coupling | M3019 | M3019 | M3019 | M3019 | M3019 | M3019 | M3019 | M3019 | M3019 | M3019 |
| Washer, Impulse | ||||||||||
| Coupling | M3172 | M3172 | M3172 | M3172 | – | – | – | – | – | – |
| Impulse Coupling Ass. | M3050 | – | M3050 | – | – | – | – | – | – | – |
| Oil Seal | M3062 | M3062 | M3062 | M3062 | – | – | – | – | – | – |
| Pressure Vent Plug | – | – | M3179 | M3179 | M3179 | M3179 | – | – | – | M3179 |
| Air Vent | M1077 | M1077 | – | – | – | – | M1077 | M1077 | M1077 | – |
| Frame | M3837 | – | M3837 | – | – | M3900 | M3900 | – | – | M3900 |
| Gasket Pressure Kit | – | – | K3307 | K3307 | K3307 | K3307 | – | – | – | K3307 |
| Ball Bearing | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 |
| Rotor | M3047 | – | M3047 | – | – | – | – | – | – | – |
| Bearing Cap Assembly | – | – | – | – | – | – | – | – | – | – |
| Bearing Cap Clamp | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 |
| Screw | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 |
| Contact Pt. Kit-Primary | M3081 | M3081 | M3081 | M3081 | M3081 | M3081 | M3081 | M3081 | M3081 | M3081 |
| Contact Pt. Kit-Second. | – | – | – | – | – | – | – | – | – | – |
| Rotor Gear | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 |
| Woodruff Key | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 |
| Coil Wedge | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 |
| Screw | – | – | – | – | – | – | – | – | – | – |
| Coil** (see below) | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 |
| Screw | M2555 | M2555 | – | – | – | – | M2555 | M2555 | M2555 | – |
| Adapter | – | – | – | – | – | – | – | – | – | – |
| Screw | – | – | – | – | – | – | – | – | – | – |
| Pressure Tube Fitting | – | – | M3180 | M3180 | M1280 | M1280 | – | – | – | M1280 |
| Air Vent with Hood | M3084 | M3084 | – | – | – | – | M3084 | M3084 | M3084 | – |
| Screw | M3015 | M3015 | – | – | – | – | M3015 | M3015 | M3015 | – |
| Housing, Distributor | M3902 | M3902 | M3902 | M3902 | M3902 | M3902 | M3902 | M3902 | M3902 | M3902 |
| Condenser | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 |
| Distributor Block & | ||||||||||
| Gear Assembly | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 |
| Washer | M2532 | M2532 | – | – | – | – | M2532 | M2532 | M2532 | – |
| Bearing Kit | K3320 | K3320 | K3320 | K3320 | K3319 | K3319 | K3319 | K3319 | K3319 | K3319 |
| Carbon Brush | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 |
| Screw | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 |
| Spacer | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 |
| Description | 6361 | 6362 | 6363 | 6364 | 6365 | 6367 | 6371 | 6380 | 6382 | 6390 |
| Cotter pin | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 | M2556 |
| Nut, Impulse Coupling | M3019 | M3019 | M3019 | M3019 | M3492 | M3019 | M3492 | M3019 | M3019 | M3019 |
| Washer, Impulse | ||||||||||
| Coupling | – | – | M3172 | – | – | – | – | – | M3172 | M3172 |
| Impulse Coupling Ass. | – | M3050 | – | – | – | – | – | M3050 | M3050 | – |
| Oil Seal | – | M3062 | – | M3062 | – | M3062 | – | M3062 | M3062 | – |
| Pressure Vent Plug | M3179 | – | M3179 | – | M3179 | – | – | – | – | – |
| Air Vent | – | M1077 | – | M1077 | – | M1077 | M1077 | M1968 | M1968 | M1077 |
| Frame | – | M3837 | M3900 | – | M3900 | – | M3900 | – | – | M3900 |
| Gasket Pressure Kit | K3307 | – | K3307 | – | K3307 | – | – | – | – | – |
| Ball Bearing | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 | M3006 |
| Rotor | – | M3047 | – | – | – | – | – | M3047 | M3047 | – |
| Bearing Cap Assembly | – | – | – | – | – | – | – | – | – | – |
| Bearing Cap Clamp | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 | M3018 |
| Screw | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 | M3221 |
| Contact Pt. Kit-Primary | M3081 | M3081 | M3637 | M3081 | M3637 | M3081 | M3637 | M3081 | M3081 | M3637 |
| Contact Pt. Kit-Second. | – | – | M3637 | – | M3637 | – | M3637 | – | – | – |
| Rotor Gear | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 | M3828 |
| Woodruff Key | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 | M2536 |
| Coil Wedge | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 | M3040 |
| Screw | – | – | – | – | – | – | – | – | – | – |
| Coil** (see below) | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 | M3975 |
| Screw | – | M2555 | – | M2555 | – | M2555 | M2555 | M2555 | M2555 | M2555 |
| Adapter | – | – | M3154 | – | – | – | – | – | – | M3154 |
| Screw | – | M3125 | – | – | – | – | – | – | M3125 | – |
| Pressure Tube Fitting | M1280 | – | M1280 | – | M1280 | – | – | – | – | – |
| Air Vent with Hood | – | M3084 | – | M3084 | – | M3084 | M3084 | M3084 | M3084 | M3084 |
| Screw | – | M3015 | – | M3015 | – | M3015 | M3015 | M3015 | M3015 | M3015 |
| Housing, Distributor | M3902 | M3902 | – | M3902 | – | M3902 | – | M3902 | M3902 | – |
| Condenser | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 | M3183 |
| Distributor Block & | ||||||||||
| Gear Assembly | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 | K3823 |
| Washer | – | M2532 | – | M2532 | – | M2532 | M2532 | M2532 | M2532 | M2532 |
| Bearing Kit | K3319 | K3320 | K3302 | K3320 | K3302 | K3320 | K3302 | K3320 | K3320 | K3302 |
| Carbon Brush | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 | M3215 |
| Screw | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 | M3021 |
| Spacer | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 | M3826 |
